Advance Concrete Forms
All Advance forming systems come in widths of 24" to 4" with all hardware attached. Form heights range from 2' to 10'. All Advance forms are produced with 120/120 High Density Overlay (HDO) plywood that meets APA Standards of PS-1
Standard In Stock Bar Spaces
9'4" 7 Bar x 24" Panel
The 9'4" 7 Bar forming system is designed for residential or light commercial work.(it matches our 8' 6 Bar system)
Forms in the 8' 6 Bar Forming System (16" on center) include: 9'4" (7 Bar) / 8' (6 Bar) / 6'8" (5 Bar) / 5'4" (4 Bar) / 4' (3 Bar) / 2'8" (2 Bar). The top bar is 8" from the top of form.
7 Bar Space is:8-24-40-56-72-88-104
9' 6 Bar x 24" Panel
The 9' 6 Bar Panel is a solid choice (that conveniently matches the first 5 bars on our 8' 5 bar system) for your over height work. The top bar is 10" from the top of form.
6 Bar Space is:8-24-42-62-82-98
8'6" 5 Bar x 24" Panel
The 8'6" 5 Bar space system is very versatile form with the ability to be able to pour down inside the form at the 8' mark or pour a 9' wall with 2x8 ladder. The top bar is 14" from the top of form.
8'6" Bar space is 8-26-44-64-88.
8' 6 Bar x 24" Panel
The 8' 6 Bar forming system is designed for residential or light commercial work. Every form in the 8' 6 bar forming system is designed with 16" on center bar spacing. The 8' 6 bar forming system, because of its bar spacing, allows stacking of forms to create acceptable form heights above 8'.
Forms in the 8' 6 Bar Forming System (16" on center) include: 9'4" (7 Bar) / 8' (6 Bar) / 6'8" (5 Bar) / 5'4" (4 Bar) / 4' (3 Bar) / 2'8" (2 Bar). The top bar is 8" from the top of form.
6 Bar Space is:8-24-40-56-72-88
8' 5 Bar x 24" Panel
The 8' 5 Bar system came about as a result of the addition pumping and vibrating. The extra bar added strength. The top bar is 14" from the top of form.
5 Bar Space is:8-24-42-62-82
8' 4 Bar x 24" Panel
The 8' 4 Bar System (the original) uses less ties saving time and money. The top bar is 20" from the top of form.
4 Bar Space is:8-28-52-76
Under 8'
Forms under 8' are available in all bar spacings. Typical sizes are 6', 5'4", 5', and 4'. Non typical are available upon request.
Custom Bar Space
We can order or help you design any bar space to fit your current or future forming needs. Just send us the measurments from the bottom of form to center of Bar(s). Give us call today and see the difference in quality of product and customer service we can provide to your business.
